Power Your Home with Reliable Solar Energy Storage
Experience dependable energy storage with our 10kWh LiFePO4 Powerwall — the ideal solution for residential solar systems. Known for its high capacity, powerful output, low self-discharge, and excellent temperature tolerance, this battery is built for performance. You can even connect up to 30 units in parallel, reaching a total capacity of 307kWh.
The SW-48V Series features advanced BMS technology, enabling seamless communication with 12 leading inverter brands. Supported interfaces include RS485 (SRNE, Growatt, LuxPower, Deye, Voltronic) and CAN BUS (Deye, SOFAR, GoodWe, Growatt, Victron, Studer, SMA).
Certified under the strict UL 1973 standard and backed by a 5-year warranty and technical support, this solar battery is a safe, long-term energy solution for your home.
| Product Specifications | |||
|---|---|---|---|
| Model | SW-48V100 | SW-48V200 | SW-48V300 |
| Rated Voltage | 51.2V | ||
| Capacity (Ah) | 100 | 200 | 300 |
| Pack Configuration | 16S1P | 16S2P | 16S3P |
| Energy (kWh) | 5.12 | 10.24 | 15.36 |
| Dimension (MM) | 540×490×147 | 820×490×147 | 950×600×190 |
| Recommended Charge Current | 50A | 100A | 150A |
| Recommended Discharge Current | 100A | 100A | 150A |
| Weight (Kg) | 53 | 95 | 130 |
| Discharge Voltage | 47V | ||
| Charge Voltage | 55V | ||
| Communication | RS232, RS485, CAN, WIFI (Optional), Bluetooth (Optional) | ||
| Enclosure Protection | IP22, IP54/IP65 (option) | ||
| Expansion | Up to 32 units in parallel | ||
| Cycle Life | > 6000 cycles, 25ºC | ||
| Certification | IEC62619, UL1973, UN38.3, CE | ||
